USB C Breakout Board - Vertical
The USB Type-C connector is intended to supersede a wide range of existing USB connectors. It is reversible and can serve in both USB host and USB device roles, allowing either end of a cable to be plugged into a receptacle with either side up, and it can support negotiation of increased power (up to 20V and 5A) and alternate uses of the USB interface wires.
The USB-C connector’s 24 tightly-spaced pins make it difficult to use in a hobby project or prototype design. This breakout board helps by providing access to the connector’s pins for power (V+ and V-), USB 2.0 differential data (D+ and D−), and Configuration Channel (CC). Each of these pins is broken out into a 1x5 row of 2.54mm spaced pins on the board.
Quick Spec
- USB Connector: Type-C
- Mounting Style: Vertical
- Data Speed: USB 2.0
- Nominal Voltage: 5V
- Pins: V+, D-, D+, CC, V-
- Dimensions: 16 x 16 x 12.5mm
Shipping List
- 1 x USB C Breakout Board - Vertical
USB C Breakout Board - Vertical
- Brand: Generic
- Product Code: USBC-VER
- Weight: 0.002kg
- Product Status : Active
