ESP32-Trinity Controller for HUB75 Display Panel
ESP32-Trinity is an open-source ESP32 board designed for controlling HUB75 matrix panels. It requires an RGB LED Matrix, a power supply, and additional hardware to function. It comes with many examples and projects that can be tried out to get started. For further information on how to set up the Trinity and its specifications, check out Resources section.
Board Layout
Code
Resources
Shipping List
- 1 x ESP32-Trinity Controller for HUB75 Display Panel
- 1 x LDR
- 1 x Header Set
ESP32-Trinity Controller for HUB75 Display Panel
- Brand: Makerfabs
- Product Code: BRIANESPTR
- Weight: 0.044kg
- Product Status : Active
Stock
| Warehouse | Stock Status | Location |
|---|---|---|
| Centurion | No Stock | |
| Stellenbosch | No Stock |
We ship free of charge between branches to complete your order.
-
R978.00 (Inc Tax: R1,124.70)
