DF Robot SIM7600-H-M2 4G LTE Communication Module
The DFRobot SIM7600-H-M2 is a high-performance LTE Cat 4 communication module designed to deliver reliable global cellular connectivity for IoT and embedded systems. Supporting multiple network standards including LTE-TDD, LTE-FDD, HSPA+, GSM, GPRS, and EDGE, it offers fast data transfer speeds of up to 150Mbps downlink and 50Mbps uplink. Built in an M.2 B-Key form factor, the module integrates seamlessly into compatible systems, making it ideal for applications such as industrial routers, telematics, remote monitoring, and smart devices.
In addition to cellular connectivity, the module features integrated multi-constellation GNSS support including GPS, GLONASS, BeiDou, Galileo, and QZSS for accurate positioning. It supports a wide range of communication protocols and operating systems, including Windows, Linux, and Android, and can be easily configured via standard AT commands. With multiple interfaces such as UART, USB, and GPIO, along with support for features like FOTA updates and secure protocols, this module provides a flexible and scalable solution for advanced IoT deployments.
Quick Spec
- Form Factor: M.2 B-Key
- Network Support: LTE-FDD / LTE-TDD / HSPA+ / GSM / GPRS / EDGE
- Data Speed:
- LTE: 150Mbps (DL) / 50Mbps (UL)
- HSPA+: 42Mbps (DL) / 5.76Mbps (UL)
- GNSS Support: GPS, GLONASS, BeiDou, Galileo, QZSS
- Interface: UART, USB, GPIO
- SIM Support: 1.8V / 3.0V
- Antenna Interface: IPEX4 (LTE main, diversity, GNSS)
- Supply Voltage: 3.0V – 4.2V
- Operating Temperature: -40°C to +85°C
- Dimensions: 42.0 × 31.4 × 3.8 mm
Dimensions
Resources
Shipping List
- 1 x DF Robot SIM7600-H-M2 4G LTE Communication Module
DF Robot SIM7600-H-M2 4G LTE Communication Module
- Brand: DF Robot
- Product Code: TEL0158
- Weight: 0.011kg
- Product Status : Active
Stock
| Warehouse | Stock Status | Location |
|---|---|---|
| Centurion | No Stock | |
| Stellenbosch | No Stock |
We ship free of charge between branches to complete your order.
-
R882.00 (Inc Tax: R1,014.30)
