AgroSense Valve & Water Flow - LoRaWAN

The AgroSense Valve & Water Flow sensor is an intelligent irrigation controller designed for remote water management over LoRaWAN®. It integrates an ultra-low-power pulse solenoid valve with a high-precision YF-S201C Hall Effect Flow Sensor, enabling both real-time flow monitoring and reliable valve control. With a rugged IP68-rated enclosure, built-in solar charging, and support for global LoRaWAN® bands (EU868/US915), it’s built for long-term outdoor deployment in agricultural and industrial applications.



Operating on LoRaWAN® V1.0.3 OTAA Class C, the device maintains a stable network connection for frequent uplinks and responsive control. Users can adjust update intervals, switch the valve ON/OFF remotely, and schedule automated irrigation tasks. Local data logging (up to 3,300 records) ensures no data loss during connectivity interruptions, while end-to-end encryption keeps communication secure.

Quick Spec

• Model: AGLWVF
• Communication: LoRaWAN® V1.0.3 OTAA Class C
• Frequency Bands: EU868 / US915
• Transmission Range: Up to 2 km (city) / 10 km (open field)
• Receiver Sensitivity: -137 dBm
• Transmit Power: 22 dBm
• Valve Type: Pulse solenoid valve (retains state on power loss)
• Flow Sensor: YF-S201C Hall Effect, ±3% accuracy
• Flow Range: 0–1.75 MPa
• Valve Pressure Range: 0.02–1 MPa
• Connections: G1/2 (20 mm) threads
• Operating Temp: -40 °C ~ 85 °C
• Protection: IP68
• Power Supply: 2 × 18650 Li-ion batteries + 6V 1W solar panel
• Data Storage: Up to 3,300 records
• Compatibility: TTN, Datacake, CloudStudio
• Mounting: Wall mount
• Dimensions: 115 × 85 × 35 mm

Product Video

Resources

• Product Page
• Product Wiki
• GitHub

Shipping List

• 1 x AgroSense Valve & Water Flow - LoRaWAN

AgroSense Valve & Water Flow - LoRaWAN

• Brand: Makerfabs
• Product Code: AGVWFLC01
• Weight: 0.484kg
• Product Status : Active

Stock

Warehouse	Stock Status	Location
Centurion	No Stock
Stellenbosch	No Stock
Bulk Location	No Stock

We ship free of charge between branches to complete your order.

• R915.00 (Inc Tax: R1,052.25)
