Logic Level Converter - 8 Channel

This 8-channel bidirectional logic-level converter safely connects devices using different logic voltages, including 3.3V and 5V. It also supports voltages such as 1.8V and 2.8V. Its eight bidirectional channels suit I²C, data buses, TTL serial and standard digital signals. BSS138 N-channel MOSFETs and pull-up resistors provide reliable voltage translation.

Quick Spec

• Compatible: 1.8V, 2.8V, 3.3V and 5V
• Direction: 8 Channel Bi Directional / Unidirectional
• Chipset: BSS138 N Channel Mosfet
• Dimensions: 27.6 x 13.6mm

Basic Operation

The level converter is very easy to use. The board needs to be powered from the two voltages sources (high voltage and low voltage) that your system is using. High voltage (5V for example) to the ‘HV’ pin, low voltage (3.3V for example) to ‘LV’, and ground from the system to the ‘GND’ pin.

Shipping List

• 1 x Logic Level Converter - 8 Channel
• 2 x 10-Pin Male SIL Header

Logic Level Converter - 8 Channel

• Brand: Generic
• Product Code: LEVEL-8P
• Weight: 0.003kg
• Product Status : Active
