Wave 8MP Camera Module IMX415 IR-CUT
The Wave 8MP Camera Module with IMX415 sensor delivers outstanding image quality with high SNR, excellent low-light performance, and minimal distortion. Featuring a 98° wide-angle lens, it captures detailed images with a resolution of 3840x2160 at approximately 8.29MP, making it ideal for high-definition recording and surveillance applications.
With a large F2.0 aperture, 1/2.8" CMOS sensor, and less than 1% distortion, this full-color camera provides sharp, clear visuals in various lighting conditions. The module includes a 0.5mm pitch (22-pin) FPC camera cable for easy integration with compatible devices.
Quick Spec
- Sensor: Sony IMX415
- Resolution: ±8.29MP (3840x2160)
- Lens: 98° wide-angle, F2.0 aperture
- Distortion: <1%
- CMOS Size: 1/2.8"
- Focal Length: 3.95mm
- Unit Cell Size: 1.45μm x 1.45μm
- Dimensions: 38 x 38 x 24.75mm
- Cable: Includes 0.5mm pitch (22-pin) FPC camera cable
Dimensions
Resources
Shipping List
- 1 x Wave 8MP Camera Module IMX415 IR-CUT
- 1 x 22-Pin FPC Cable - ±15cm (0.5mm pitch)
Wave 8MP Camera Module IMX415 IR-CUT
- Brand: Waveshare
- Product Code: W28524
- Weight: 0.018kg
- Product Status : Active
